1220x2440mm
HUABAO
4411142900
8mm melamine paper laminated MDF:
Size: 1220*2440*6/8/12/15/18mm;
Face/ Back: melamine paper both sides;
Surface treatment: matte Finish/Light finish
Density: 680-830 kg/m3
No. | Test Items | Technical Specification | Unit | Test Result |
1 | Moisture Content | 4~13 | % | 5.8 |
2 | Density | 670~880 | Kg/m3 | 730 |
3 | Density Tolerance | ±7.0 | % | ±1.4 |
4 | Expansion ration in thickness | ≤10 | % | 8.8 |
5 | Internal bonding | ≥0.45 | Mpa | 0.49 |
6 | Modulus of rupture | ≥20 | Mpa | 26.8 |
7 | Modulus of elasticity | ≥2200 | Mpa | 3280 |
8 | Screw holding | Face≥1000 | N | 1120 |
Side≥800 | 870 | |||
9 | Surface bonding | Mpa | 1.28 | |
10 | Formal Dehyde Emission | E1: ≤9.0 | mg/100g | 4.9 |
E2: ≤30.0 | 20 |
8mm melamine paper laminated MDF:
Size: 1220*2440*6/8/12/15/18mm;
Face/ Back: melamine paper both sides;
Surface treatment: matte Finish/Light finish
Density: 680-830 kg/m3
No. | Test Items | Technical Specification | Unit | Test Result |
1 | Moisture Content | 4~13 | % | 5.8 |
2 | Density | 670~880 | Kg/m3 | 730 |
3 | Density Tolerance | ±7.0 | % | ±1.4 |
4 | Expansion ration in thickness | ≤10 | % | 8.8 |
5 | Internal bonding | ≥0.45 | Mpa | 0.49 |
6 | Modulus of rupture | ≥20 | Mpa | 26.8 |
7 | Modulus of elasticity | ≥2200 | Mpa | 3280 |
8 | Screw holding | Face≥1000 | N | 1120 |
Side≥800 | 870 | |||
9 | Surface bonding | Mpa | 1.28 | |
10 | Formal Dehyde Emission | E1: ≤9.0 | mg/100g | 4.9 |
E2: ≤30.0 | 20 |
